产品介绍
| Lamp/光源 | |
| Rated Voltage/额定电压 | 220V |
| Lamp Type/灯具类型 | LED |
| Rated Power (LED Lamp)/灯数量*功率 | 4x400W防爆灯头 |
| Luminous Efficiency/发光效率（光通量） | 120Lm/W |
| Protection Class/防护等级 | IP65 |
| Color Temperature/色温 | 5700K |
| Lamp Service Life/寿命 | 80000h |
| lifter/升降杆 | |
| Lighting direction Adjust the horizontal direction/照明方向调节水平方向 | 360° |
| Lighting direction adjustment tilt rotation/照明方向调节仰俯旋转 | 90° |
| Lifting height/number of knots/升降高度/节数 | 9m/9节knots |
| Telescopic mast/升降杆 | Hydraulic rod/液压杆 |
| Lifting mode/升降方式 | Electric switch control/电动开关控制 |
| Lifting equipment/升降设备 | Hydraulic cylinder/液压油缸 |
| Materials/材料 | High quality low alloy steel/优质低合金钢 |
| load-bearing/承重 | 110kg |
| Generator set/发电机组 | |
| Fuel type/燃油类型 | Diesel oil/柴油 |
| Rated Voltage/额定电压 | 220V |
| Rated frequency/额定频率 | 50HZ |
| Rotational speed/转速 | 3000rpm |
| Cooling mode/冷却方式 | Air cooling/风冷 |
| Starting mode/启动方式 | Electric starting/电启动 |
| load fuel consumption/油耗 | 1.66 liters per hour/1.66升/小时 |
| Tank capacity/油箱容量 | 15L（customizable tank/可定制油箱） |
| engine/发动机 | Single cylinder, four stroke/单缸、四冲程 |
| Generator type/发电机类型 | alternator/交流发电机 |
| power/功率 | 5KW |
| Insulation class/绝缘等级 | H |
| Generator type/发电机型式 | Open shelf/开架式 |
| Trailer undercarriage/拖车底盘部分 | |
| Support mode/支撑方式 | 1000KG×4（千斤顶） |
| Tyre size/轮胎尺寸 | 185*13英寸 |
| Braking mode/刹车方式 | Handbrake device/手刹装置 |
| Wind resistance class/抗风等级 | ≤10级 grade |
| Steering guide wheel/转向导轮 | Adjustable guide wheel/可升降导轮 |
| tyre/轮胎 | inflatable/可充气 |
| Disassembly structure/拆卸结构 | Forklift lifting point/叉车起吊点 |
| lamppost/灯杆 | 350cm×35cm×35 cm |
| Lamps and lanterns/灯具 | 52cm×52cm×37cm |
| airframe/机身 | 155cm×135cm×161cm |
| Towing speed/拖行速度 | 100KM/H |
| Overall weight/整体重量 | 900公斤左右 |
| voltage/电压 | 12V |
| type/类型 | Maintenance-free lead-acid battery/免维护铅酸电瓶 |
| capacity/容量 | 40AH |
| Electrical protection/电气保护 | Automatic protection/自动保护 |
| Auxiliary configuration/辅助配置 | |
| shell/外壳 | 1.5mm钢板加工成型steel plate processing |
| Surface treatment/表面处理 | Surface spraying/表面喷塑 |
| colour/颜色 | Medium yellow/livid grey/中黄/青灰 |
| Traction device/牵引装置 | toroidal/环形 |
| Pilot lamp/指示灯 | Steering/braking/warning lights/转向/刹车/警示灯 |
